PDC15-480-0503

• POWER DISTRIBUTION CENTER - NEMA 3R
• LINE SIDE: 150A 480V 3PH SERIES 15 CAMLOCKS FEEDING,
• 1EA CB ENCLOSURE FEEDING 3EA CS8169 REC
• 1EA 30A 600V FUSED DISCONNECT (25A FUSES)
• XFMR: 30KVA 480V - 120/208V VENTILATED NEMA 3R
• LOAD SIDE: PANELBOARD- 120/208 3PH 100A MCB
• 3EA 20A 120V GFCI DUP U/G REC
• 1EA 50 125/250 REC (CS6369)
• 1EA 50 250V 3PH REC (CS8369)
• ALL REC W/ WEATHERPROOF COVERS.
• ALL REC W/ CIRCUIT BREAKER PROTECTION
• ALL MOUNTED ON A HEAVY DUTY 2 WHEEL CART W/
• 1EA 5K LIFTING EYE, AND 10" NON-FLAT TIRES.
• POWER CORD - 5FT PIGTAIL 4/4 TYPE W/ S15 MALE CAMLOCKS
• COLORS: BROWN, ORANGE, YELLOW & GREEN
• POWDER COATED ORANGE.
• Assembled with UL parts
